Attention Electrical Installer

Please Read Completely Before Installation to Insure Proper Operation of Suppression Unit

• This SineTamer Suppression unit incorporates special Frequency Circuitry and the installation of the wire lead length is critical in order to achieve proper results.
• Lead lengths are to be as short as possible. Do not incorporate severe 90 bends in the wiring.  The suppressor leads are suggested to be cut to length and fed directly into the breaker with no wire loops or sagging wire within the panel.
• Units are designed to have lead lengths of wire approximately 6-8 inches in length, from the outlet of the suppressor to the tie in point of either the buss or a breaker. Try to place the unit in any position possible to ensure all leads are approximately the same length or as close as possible.
• The SIneTamer incorporates internal thermal fusing on all modes of protection. This enables the unit to be attached directly to the buss bar if required.  We recommend attaching to a breaker whenever possible, to avoid shutdowns in case removal is needed.
• The SineTamer suppressor has no load draw, so breaker size is unimportant.
• Please read installation instructions thoroughly which are included with unit.
